PT-1100-300 electro hydraulic servo universal testing machine
SYSTEM UNIVERSAL TESTING MACHINE COMPUTER
Introduction of electro-hydraulic servo universal testing machine
PT-1100-300 type microcomputer controlled electro-hydraulic servo universal testing machine is used in the cylinder of the main engine, which is mainly used for metal, nonmetal tensile, compression, bending and shear test. Applies to metallurgy, construction, light industry, aviation, aerospace, materials, tertiary institutions, scientific research units and other fields. Test operation and data processing in accordance with the requirements of GB228-2002 "metal tensile test method for room temperature materials".
Main performance index:
1, the maximum test force: 300kN;
2, test force measurement range: 6KN-300kN;
3, the test force shows the value of accuracy: 1%;
4, displacement measurement resolution: 0.01mm;
5, deformation measurement: standard configuration distance 50mm, the maximum deformation of 10mm.
6, deformation measurement accuracy: 0.5%
7, constant, constant deformation, constant displacement control range: 0.4%~100%FS
8, constant, constant deformation, constant displacement control precision:
Set the value of <10%FS, set the value of less than 1%
The set value is not less than 10%FS, within the set value of + 0.5%
9, the deformation rate control accuracy: the rate of <0.05%FS is 2%
The rate is not less than 0.05%FS + 0.5% value set
10, the piston is the largest mobiles speed: 100mm/min;
11, the maximum tensile test space: 650mm (including the piston stroke)
12, the maximum compression space: 550mm (including the piston stroke)
13, flat specimen holder thickness: 0-15mm
14, round specimen clamping diameter: diameter of 6- 26mm.
15, size: 200 * 200mm
16, bending test of rolling distance: 350 mm
17, rolling width: 140mm
18, fulcrum diameter: 30mm
19, piston stroke: 200mm;
20, clamping: hydraulic clamping
21, sensor and amplifier: oil pressure sensor, plug in the PC machine internal control amplifier, automatic zero adjustment
22, shape size: host: 860 x 560 x 2100mm
Oil source: 1100 x 700 x 950mm
23, machine weight: 2200 kg
