Using windows work platform, the parameters set all in the form of a dialog box, the operation is simple;

The use of a single screen operation, no picture switch;

The software interface has three languages: Simplified Chinese, traditional Chinese and English;

Can self planning and testing report mode;

Test data can be directly called in the main screen;

Data comparison of multiple curves can be selected by using the method of translation, comparison and so on;

With a variety of measurement units, metric can switch with automatic return function;
With automatic correction function;
With automatic magnification function to achieve the most appropriate size of the graphics;
Custom test method;
Operation analysis of test data;
It can be used to test the tensile, compressive, flexural, stripping, holding, holding pressure, fatigue and so on.

Product model

PT-8216M

PT-8216A

PT-8216B

PT-8216C

Capacity selection

1000、2000、5000、10000kg Optional one

Measurement and control software

Perfect test software based on Windows2000/xp

Accuracy of measurement

better than ±1.0%

Force resolution

1/100,000

Effective range of measurement

0.5~100%F.S

Deformation display accuracy

better than ±1.0%

Test speed range

0.5～200mm/min，Can be arbitrarily set

Test space (W×D×H)

60×60×60cm

80×80×80cm

100×100×100cm

120×120×120cm

150×150×150cm

Unit switch

A variety of measurement units, including international units, users can also customize the required units

Stop mode

Upper and lower limit safety setting, emergency stop button, program strength and elongation setting, test piece failure

Special function

Can do holding pressure test

Standard configuration

Commercial computer 1, color printer 1

Optional configuration

The 1 seat heightening test machine

無

Machine size (W×D×H)

92×60×144cm

125×80×148cm

142×100×171cm

162×120×191cm

200×150×218cm

Machine weight

About 150kg

About 350kg

About 400kg

約500kg

Power

Digital AC servo motor

Power Supply

1PH,220V,50/60Hz，15A Or specify
